Gigabyte UD1300GM – 1300W 80+ Gold Modular PCIe 5.0 Power Supply

Type

Intel Form Factor ATX 12V v3.0

PFC

Active PFC (>0.9 typical)

Input Voltage

100-240 Vac (full range)

Input Current

15-6.5A

Input Frequency

60-50 Hz

Output Capacity

1300W

Dimension

150 x 160 x 86 mm

Fan Type

140mm double ball bearing fan

80 PLUS

Gold

Efficiency

90% at typical load

MTBF

>100,000 hours

Protection

OVP/OPP/SCP/UVP/OCP/OTP

Power Good Signal

100-150ms

Hold Up Time

>16ms

Cable Type

Flat, All black

Connectors

ATX/MB 20+4 Pin x 1 : 610mm*1

CPU/EPS 4+4 Pin x 2 : 650mm*2

PCIe 16 Pin x 1: 700mm*1

PCIe 6+2 Pin x 8 : 650mm+150mm*3, 650mm*2

SATA x 12 : 650mm+150mm+150mm+150mm*3

4 Pin Peripheral x 6+4-Pin floppy x 2 : 600mm+150mm+150mm+150mm*2
