Black Diamond Dia-65.2 6.5-Inch Coaxial Car Speakers – 2-Way, 4-Ohm, 60W

Description

Key Features:

• MAX Power Handling: 180W
• RMS Power Handling: 60W
• Nominal Impedance: 4 OHMS
• Sensitivity: (1w/1m):87.8db
• Frequency Response: 40Hz – 20KHz
• Recommended Hi Pass Crossover: 120 Hz
• Number of Ways: 2-Way
• Pair or Single: Pair
• Grill Included: Yes

Woofer Specifications

• Voice Coil Diameter: 1
• Voice Coil Former Material: KSV
• Winding Material: PE
• Cone Material: PPI
• Surround Material: Rubber
• Basket Material: Acero
• Basket Color Finish: Black
• Magnet Material: Ferrite
• Magnet Weight: 5.3 oz

Tweeter Specifications

• Nominal Diameter: 1
• Voice Coil Diameter: 0.85
• Voice Coil Former Material: KSV
• Winding Material: PE
• Diaphragm Material: PEI Dome
• Magnet Material: Neodymiun

Measurements

• Overall Diameter: 5.15 / 131mm
• Overall Depth: 2.36 / 60mm
• Front Mount Baffle Cutout: 3.74 / 95mm
• Mounting Depth: 1.79 / 45.5mm
• Motor Diameter: 2.71 / 69mm
