be quiet! Pure Rock 3 LX RGB CPU Cooler – Low-Profile Air Cooler with Addressable Lighting (BK040)

GENERAL DATA

Model

Pure Rock 3 LX

TDP (W)

190

Color option

Black

Overall dimensions without mounting material
(L x W x H), (mm)

71 x 124 x 154

Total weight (kg)

0.57

Socket compatibility Intel

1851 / 1700 / 1200 / 1150 / 1151 / 1155

Socket compatibility AMD

AM5 / AM4

Overall noise level (dB(A)) @ 50/75/100% (rpm)

12.4 / 24.4 / 31.2

Number of fans

1

HEATSINK SPECIFICATIONS

Dimensions (L x W x H), (mm)

46 x 124 x 154

Fin material

Aluminum

Surface treatment

Electrophoresis

Base material

Aluminum / Copper

CPU contact surface

Heat pipe direct touch

Heatpipe number / Diameter (mm)

4 / 6

FAN SPECIFICATIONS

Fan model

Light Wings LX 120mm PWM

Fan dimensions (mm)

120 x 25 x 120

Speed @ 100% PWM (rpm)

2000

Airflow at 100% PWM / 12V (CFM / m3/h)

61.8 / 105.1

Air Pressure at 100% PWM / 12V (mm H2O)

2.51

Bearing technology

Rifle

Motor technology

4-pole fan motor

Rated Voltage (V)

12

Input current (A)

0.15

Safety current (A)

0.30

Input power (W)

5.4

Connector

4-pin PWM

Lighting connector

œ“

Cable length (mm)

120

Lifespan (h / 25 °C)

60,000

ACCESSORIES

Thermal grease (Type)

Applied

Mounting set

Intel & AMD

User manual languages

CN, DE, EN, ES, FR, JP, PL, RU, TW, UA

SAFETY CERTIFICATION

Approvals

CE, UKCA, UL

ENVIRONMENTAL DIRECTIVES

RoHS

œ“

WEEE

œ“

Triman

œ“
