Description
| Specification | Details |
|---|---|
| Model | ASUS ProArt X870‑Creator WiFi 7 |
| CPU Socket | AM5 |
| Chipset | AMD X870 |
| Memory | 4 × DDR5 DIMM slots, Dual‑Channel, up to 8000+ MHz, ECC/Non‑ECC, AMD EXPO™ & AEMP support |
| Graphics Output | 2 × USB4 (40 Gbps) Type‑C, 1 × USB4 20 Gbps Type‑C, 1 × HDMI 2.1 (4K@60 Hz), 1 × DisplayPort (input only) |
| Expansion Slots | 2 × PCIe 5.0 x16 (Q‑Release Slim, supports x16 or x8/x8), additional chipset x4 slot |
| Storage | 4 × M.2 slots (M.2_1 & M.2_2 PCIe 5.0 x4 for Ryzen 9000/7000, others PCIe 4.0 x4), 4 × SATA 6 Gb/s ports |
| Ethernet | 1 × Marvell AQtion 10 Gb Ethernet, 1 × Intel 2.5 Gb Ethernet, LANGuard |
| Wireless & Bluetooth | Wi‑Fi 7 (2×2, 2.4/5/6 GHz, up to 6.5 Gbps), Bluetooth v5.4 |
| Rear USB Ports | 2 × USB4 (40 Gbps) Type‑C, 1 × USB 20 Gbps Type‑C, 7 × USB 3.2 Type‑A, 1 × USB 2.0 Type‑A |
| Front USB Ports | 1 × USB 20 Gbps Type‑C (QC 4+ up to 30 W), 1 × USB 5 Gbps header (2 ports), 3 × USB 2.0 headers (6 ports) |
| Audio | Realtek ALC1220P 7.1 Surround, 120 dB SNR playback, 113 dB SNR recording, premium capacitors, shielding |
| Special Features | ASUS 5X Protection III (DIGI+ VRM, LANGuard, Safeslot, etc.), Q‑Design (Q‑Latch, Q‑Release, Q‑Slide, Q‑Antenna), AI Cooling II, AURA Sync, BIOS FlashBack |
| Software | Armoury Crate (Aura Sync, Fan Xpert 4 AI Cooling II), ASUS DriverHub, ProArt Creator Hub, BIOS EZ Mode, ACC Express |
| BIOS | UEFI AMI, 256 Mb flash ROM |
| Manageability | WOL by PME, PXE |
| Operating System | Windows 11 |
| Form Factor | ATX (30.5 cm × 24.4 cm) |
