Description
SPECIFICATIONS:
|
GENERAL SPECIFICATIONS |
||
|
Platform |
Desktop |
|
|
Product Family |
AMD Ryzen ¢ Processors |
|
|
Product Line |
AMD Ryzen ¢ 5 8000 G-Series Desktop Processors with Radeon ¢ Graphics |
|
|
AMD PRO Technologies |
No |
|
|
# of CPU Cores |
6 |
|
|
Multithreading (SMT) |
Yes |
|
|
# of Threads |
12 |
|
|
Max. Boost Clock |
Up to 5.0GHz |
|
|
Base Clock |
4.3GHz |
|
|
L2 Cache |
6MB |
|
|
L3 Cache |
16MB |
|
|
Default TDP |
65W |
|
|
AMD Configurable TDP (cTDP) |
45-65W |
|
|
Processor Technology for CPU Cores |
TSMC 4nm FinFET |
|
|
CPU Compute Die (CCD) Size |
178mm ² |
|
|
Package Die Count |
1 |
|
|
Unlocked for Overclocking |
Yes |
|
|
AMD EXPO ¢ Memory Overclocking Technology |
Yes |
|
|
Precision Boost Overdrive |
Yes |
|
|
Curve Optimizer Voltage Offsets |
Yes |
|
|
AMD Ryzen ¢ Master Support |
Yes |
|
|
CPU Socket |
AM5 |
|
|
CPU Boost Technology |
Precision Boost 2 |
|
|
Instruction Set |
x86-64 |
|
|
Supported Extensions |
AES, AMD-V, AVX, AVX2, AVX512, FMA3, MMX(+), SHA, SSE, SSE2, SSE3, SSE4.1, SSE4.2, SSE4A, SSSE3, x86-64 |
|
|
Max. Operating Temperature (Tjmax) |
95 °C |
|
|
*OS Support |
Windows 11 – 64-Bit Edition Windows 10 – 64-Bit Edition RHEL x86 64-Bit Ubuntu x86 64-Bit *Operating System (OS) support will vary by manufacturer. |
|
|
CONNECTIVITY |
||
|
Native USB 4 (40Gbps) Ports |
2 |
|
|
Native USB 3.2 Gen 2 (10Gbps) Ports |
2 |
|
|
Native USB 2.0 (480Mbps) Ports |
1 |
|
|
PCI Express ® Version |
PCIe ® 4.0 |
|
|
Native PCIe ® Lanes (Total/Usable) |
20 / 16 |
|
|
NVMe Support |
Boot, RAID0, RAID1 |
|
|
System Memory Type |
DDR5 |
|
|
Memory Channels |
2 |
|
|
Max. Memory |
256GB |
|
|
System Memory Subtype |
UDIMM |
|
|
Max Memory Speed |
2x1R 2x2R 4X1R 4x2R |
DDR5-5200 DDR5-5200 DDR5-3600 DDR5-3600 |
|
GRAPHICS CAPABILITIES |
||
|
Integrated Graphics |
Yes |
|
|
Graphics Model |
AMD Radeon ¢ 760M |
|
|
Graphics Core Count |
8 |
|
|
Graphics Frequency |
2800 MHz |
|
|
DirectX ® Version |
12 |
|
|
DisplayPort ¢ Version |
2.1 |
|
|
DisplayPort Extensions |
HDR Metadata |
|
|
Adaptive-Sync |
UHBR10 |
|
|
DisplayPort Max Refresh Rates (SDR) |
7680×4320 @ 60Hz 3840×2160 @ 240Hz 3440×1440 @ 360Hz 2560×1440 @ 480Hz 1920×1080 @ 600Hz |
|
|
DisplayPort Max Refresh Rates (HDR) |
7680×4320 @ 60Hz 3840×2160 @ 240Hz 3440×1440 @ 360Hz 2560×1440 @ 480Hz 1920×1080 @ 600Hz |
|
|
HDMI ® Version |
2.1 |
|
|
HDCP Version Supported |
2.3 |
|
|
USB Type-C ® DisplayPort ¢ Alternate Mode |
Yes |
|
|
Multi-Monitor Support |
Yes |
|
|
Max Displays |
4 |
|
|
AMD FreeSync ¢ |
Yes |
|
|
Wireless Display |
Miracast |
|
|
Max Video Encode Bandwidth (SDR) |
1080p630 8bpc H.264 1440p373 8bpc H.264 2160p175 8bpc H.264 1080p630 8bpc H.265 1440p373 8bpc H.265 2160p175 8bpc H.265 4320p43 8bpc H.265 1080p864 8/10bpc AV1 1440p513 8/10bpc AV1 2160p240 8/10bpc AV1 4320p60 8/10bpc AV1 |
|
|
Max Video Decode Bandwidth |
1080p60 8bpc MPEG2 1080p60 8bpc VC1 1080p786 8/10bpc VP9 2160p196 8/10bpc VP9 4320p49 8/10bpc VP9 1080p1200 8bpc H.264 2160p300 8bpc H.264 4320p75 8bpc H.264 1080p786 8/10bpc H.265 2160p196 8/10bpc H.265 4320p49 8/10bpc H.265 1080p960 8/10bpc AV1 2160p240 8/10bpc AV1 4320p60 8/10bpc AV1 |
|
|
AMD SmartAccess Memory |
Yes |
|
|
AI ENGINE CAPABILITIES |
||
|
Brand Name |
AMD Ryzen ¢ AI |
|
|
AMD Ryzen ¢ AI |
Available |
|
|
Performance |
Up to 16 TOPS |
|
|
SECURITY, VIRTUALIZATION, AND MANAGEABILITY |
||
|
AMD Enhanced Virus Protection (NX bit) |
Yes |
|
